The New 2015 SMART FOLDERS

Lovaghy Enterprise Inc. manufactures a series of customized mobile folders that give you the flexibility/advantage to fold copies Inline in the Pressroom, Mailroom or Offline with the finishing solutions you need fast. Fold a wide variety of retail inserts, financial documents, direct-mail, digest copies, magazines, tabloids and newspapers at remarkable speeds. Here is a brief list of some of the money making solutions we provide that can be a real advantage to you in your plant. Run a stream of nested shingles from the delivery to separate and fold Inline producing two or three lines of products; For more info review our Separator info; Run A3 size products to fold along a freshly glued spine and trim three sides In-line to produce A4 size booklets; Bump-turn to fold products parallel with the spine of the product and trim inline to produce multiple single copies with absolutely no wrinkling guaranteed; Run retail inserts with wraps and place the fold where you want it inline or offline; Run newspapers with the header on the bottom side or top side for choice of folder; Produce double parallel folds to create two digest copies and more. To learn more just visit us on the YouTube Channel at this link.

HQF-20 Standard Features & Specifications:

• HQF-20 Video
• Smart Folder Display: The Smart Folder Display works with a programmed PLC that controls all the inputs and outputs for each electrical component and drive. By selecting & inputting the particular shingle spacing/pagination of the copy on the monitor’s keypad, the Smart Folder automatically sets the optimized speed ratios for each particular drive.
• Internet Ready: With a dedicated Internet connection the HQF Smart Folder allows Lovaghy technicians to perform upgrades in the software and the ability to monitor the machine’s performance directly from Montreal.
• New Feature: Four Baldor Motors: A 1/3 HP gear-motor runs the entrance dump-gate while a 5HP motor provides exceptional performance for the crusher, jogger, folder and 90 degree. A third 2HP Extreme Duty Baldor Motor handles the High Speed Section. A new gearbox with a 1HP Baldor Motor drives the exiting re-shingler conveyor.
• Four Schneider Altivar 312 Motor Drives: Independently control the speed of each separate motor which are programmed to provide you with optimum performance.
• Tach Following: Manual and automatic selector button allows you to choose setting. Automatic mode follows a 0 to 10Volt signal from the press or mailroom to match speeds. Can also be programmed to follow pulse signals when required.
• Voltage: 230V 50/60 Hz – Operates in single or three phase power connection.
• Approximate Dimensions: 185.5”/471.17cm Length x 38”/0.97m Width x 69.4”/1.76m
• Height. 221.65”/563cm with Exit Jogger Attachment.
• Working Height: 35.5”/0.9017m
• New pneumatic lift: Secures positioning so that the folder doesn’t move during production.
• Approximate Weight: 2,300 lbs./1043.3 kgs.

HQF-21 Standard Features & Specifications:

• HQF-21 Video
• Comes with all the same great features of the HQF-20 and more.
• The HQF-21 Smart Folder is designed to fold up to a 48-page/48gsm newspaper with delivery of products from a mailroom delivery system.
• Folds newspapers with the header of the product located on the bottom side.

HQF-30 Standard Features & Specifications:

• HQF-30 Video
• Folds tabloids into double parallel folds
• Entrance conveyor and bump-turn are included as part of the machine and are controlled at the control panel
• Folds 35,000 copies per hour in line with the press
• Fold 24 page products into 48 pages
• Folds copies with the spine leading out
• Folds copies 17.5” in width
• Provides excellent folds when products are perforated in the center

Separator 2 Features & Specifications:

• Separator 2 Video
• Two separate one HP continuous duty Baldor AC motors
• Single phase 230VAC 50/60
• Schneider Drives - Adjustable speed control with on & off switch
• Drive is equipped with electronic board for automatic press following
• Two independent 5 to 1 ratio Baldor gear boxes able to run 85,000 copies per hour with two inch/5cm shingles
• Strong steel welded painted frame
• 16 Gauge stainless steel metal side panels and top covers
• Customized to required height
• Machine is mobile with swivel heavy duty locking castors
• Top of the line PHD slides with pneumatic controls to lift top pinning sections
• Built-in outgoing conveyor for smooth copy transfer to stackers
• Approximate weight: 800 lbs./363 kgs
• Size: 68”/1.73m in width x 56”/1.42m in length and 108”/2.74m with additional extended long conveyor

Separator 3 Features & Specifications:

• Separator 3 Video
• Three separate continuous duty AC motors
• Single or triple phase 208 to 230VAC 50/60Hz
• Three Separate Schneider Drives - Adjustable speed control with on & off switch
• Drive is equipped with electronic board for automatic press following
• 5 to 1 ratio gear box able to run 85,000 copies per hour at 50/60Hz with two inch/50mm shingle
• Strong steel welded painted frame
• 16 Gauge stainless steel metal side panels and top covers
• Customized to height of folder delivery from 26”/0.66m to 40”/1.02m standard
• Machine can be built to be mobile with swivel heavy duty locking castors
• Top of the line PHD slides with pneumatic controls to lift top pinning sections
• Built-in outgoing conveyor for smooth copy transfer to stackers
• Approximate weight: 1,500 pounds
• Size: 68” inches/1.73 meters in length x 144” inches/3.66 meters in width

Jug 'n Crush Features & Specifications:

• Excellent for work with Deserters, Separators and Trimmers or anywhere you need to accurately Jog N' Crush your stream of copies into place for optimum speed; Eliminates a lot of potential paper waste
• Comes with a powerful 3HP motor and 5 to 1 ratio gearbox for continuous duty
• Easy to read state of the art controls simplify set-up and operation
• Can be easily set up for press following
• Jogs and Crushes copies as wide as 18" into place
• Can be supplied with castors for easy placement
• Works with choice of 220VAC or 460VAC
